Product details of the concertina sliding doors
Quick Detail
Appreciated by most customers, have been deeply realized the importance of concertina sliding doors to users. The product has been recognized internationally for its performance and quality. Our concertina sliding doors can be used in multiple areas of multiple industries. The product suits for various application and has a great market prospect as it is increasingly popular in the industry.
Product Information
will present you concertina sliding doors's details in the following section.
Techniacal Data
This versatile door finds suitability in a wide range of applications, including supermarkets, shopping malls, jewelry shops, coffee shops, club bars, and brand chain stores.
| Max width | 35meters | Panel width | 11cm,15cm,22cm, 26.5cm ,29cm |
| Max Height | Manual 4.5m, motorized 6m | PC panel thickness | 1.5mm~2.0mm |
| Aluminum color | White, black, silver or custom color | Pocket width | 8% of total width |
| PC color | Transparent/white | Operation | Manual or motorized |
| Open direction | One side open or bifolding |
Description 01
◆ For panel options, there is a selection of widths available, ranging from 100mm to 300mm. The grill panel consists of 10mm aluminum rods securely fastened to a high-quality aluminum frame, ensuring optimal security and airflow. The door can be operated either manually or with a motorized system.
◆ The track system comprises a 35mm45mm aluminum track for straight door openings, while a 35mm55mm aluminum track is specifically designed for curve openings. Although the latter can be adapted for straight openings, it necessitates pre-formation using a bending machine.
◆ The Polycarbonate Folding Sliding Door has a maximum width of 35 meters and a height of 4.5 meters for manual operation or 6.0 meters for motorized operation.
◆ Each folding door is equipped with a lock set and two keys, allowing access from both sides. Additionally, a set of ground bolts and a dust cover are provided for every 1-meter width of the door.
Description 02
◆ The aluminum finish is offered in powder coating or anodized options. While the standard colors include natural aluminum, white, and black, customization is available based on customer-provided color samples.
◆ The stacking pocket size is typically around 8% of the total door width and will be precisely determined based on your specific data.
Motor specifications encompass various voltage/frequency options such as single phase 220V/50Hz, three phase 380V/50Hz, and 110V/60Hz. Multiple remote controls are included, and the lifting forces range from 300KG to 2000KG. Optional features consist of a backup battery, alarm system, stopping device, and cellphone control.
◆ A generous 5-year warranty is provided for the folding sliding security grilles, and in the event of unresolved quality issues, we offer product replacements.
◆ For shipment and delivery, LCL orders are securely packed in plywood boxes, while FCL orders utilize foam and carton packaging.
Item Description
The Polycarbonate Folding Sliding Door has a maximum width of 35 meters and a height of 4.5 meters for manual operation or 6.0 meters for motorized operation. Each folding door is equipped with a lock set and two keys, allowing access from both sides. Additionally, a set of ground bolts and a dust cover are provided for every 1-meter width of the door.
