Collapsible Sliding Door 1.5mm~2.0mm Manual 4.5mwith Custom Services 1

Collapsible Sliding Door 1.5mm~2.0mm Manual 4.5mwith Custom Services 2

Collapsible Sliding Door 1.5mm~2.0mm Manual 4.5mwith Custom Services 3

Collapsible Sliding Door 1.5mm~2.0mm Manual 4.5mwith Custom Services 4

Collapsible Sliding Door 1.5mm~2.0mm Manual 4.5mwith Custom Services

Max Height:

Manual 4.5m, motorized 6m

Aluminum Color:

White, black, silver or custom color

Panel Thickness:

1.5mm~2.0mm

Operation:

Manual or motorized

Inquiry

Product details of the collapsible sliding door

Product Information

In order to be more attractive, our has also established a team with professional design experience in collapsible sliding door industry for years. The quality standards of this product are based on government and industry requirements. tries and keeps our prices as low as possible.

Techniacal Data

This versatile door finds suitability in a wide range of applications, including supermarkets, shopping malls, jewelry shops, coffee shops, club bars, and brand chain stores.

Max width	35meters	Panel width	11cm,15cm,22cm, 26.5cm ,29cm
Max Height	Manual 4.5m, motorized 6m	PC panel thickness	1.5mm~2.0mm
Aluminum color	White, black, silver or custom color	Pocket width	8% of total width
PC color	Transparent/white	Operation	Manual or motorized
Open direction	One side open or bifolding

Description 01

◆ For panel options, there is a selection of widths available, ranging from 100mm to 300mm. The grill panel consists of 10mm aluminum rods securely fastened to a high-quality aluminum frame, ensuring optimal security and airflow. The door can be operated either manually or with a motorized system.

◆ The track system comprises a 35mm45mm aluminum track for straight door openings, while a 35mm55mm aluminum track is specifically designed for curve openings. Although the latter can be adapted for straight openings, it necessitates pre-formation using a bending machine.

◆ The Polycarbonate Folding Sliding Door has a maximum width of 35 meters and a height of 4.5 meters for manual operation or 6.0 meters for motorized operation.

◆ Each folding door is equipped with a lock set and two keys, allowing access from both sides. Additionally, a set of ground bolts and a dust cover are provided for every 1-meter width of the door.

Description 02

◆ The aluminum finish is offered in powder coating or anodized options. While the standard colors include natural aluminum, white, and black, customization is available based on customer-provided color samples.

◆ The stacking pocket size is typically around 8% of the total door width and will be precisely determined based on your specific data.

Motor specifications encompass various voltage/frequency options such as single phase 220V/50Hz, three phase 380V/50Hz, and 110V/60Hz. Multiple remote controls are included, and the lifting forces range from 300KG to 2000KG. Optional features consist of a backup battery, alarm system, stopping device, and cellphone control.

◆ A generous 5-year warranty is provided for the folding sliding security grilles, and in the event of unresolved quality issues, we offer product replacements.

◆ For shipment and delivery, LCL orders are securely packed in plywood boxes, while FCL orders utilize foam and carton packaging.

Item Description

The Polycarbonate Folding Sliding Door has a maximum width of 35 meters and a height of 4.5 meters for manual operation or 6.0 meters for motorized operation. Each folding door is equipped with a lock set and two keys, allowing access from both sides. Additionally, a set of ground bolts and a dust cover are provided for every 1-meter width of the door.
